Universal Motor Starting Relay
ICM's award-winning Universal Motor Starting Relay incorporates patented differential voltage sensing and a non-positional mounting configuration to offer a single replacement for all standard potential relays. Great way to reduce inventory. Replacement for all standard potential relays.
- Patented differential voltage sensing
- No user-adjustments required
- Non-positional mounting configuration
- 50A Switching capabilities
- Universal mounting bracket for easy installation
- .250″ quick connect termination
- Safety timer
- Ideal for A/C, commercial refrigeration, heat pump, or any single-phase motor application up to 10HP
Input:
- Voltage Rating: 110-270 VAC, Single Phase
- Maximum Voltage Contact Rating: 502 VAC (absolute)
Motor Power Rating: Up to 10 HP
Operating Position: Non-positional
Safety Time Out: Approximately 1-second per 100 microfarads
Consumption: 5VA max.
Insulation: Class B (130°C); Conforms to IEC 1000- standards (6kV impulse / 6kV contact)
Mechanical:
- 1 x 10(6)
Electrical:
- 1 x 10(6) at 16A 400 VAC
- 5 x 10(5) at 35A 400 VAC (break only)
- 5 x 10(5) at 50A 400 VAC (break only)
Contact Rating:
- 30A (break only), 400 VAC cos Ø = 0.7 to 0.8
- 50A (break only), 400 VAC cos Ø = 0.7 to 0.8
Weight/Dimensions
- Weight: 0.2 lb.
- Height: 1.625″
- Width: 2″
- Length: 2″
All standard potential relays
Supco: APR5, SUPR
