Time Delay Relays
Delay On Make Relays (DOM)
ICM103
Switch Selectable Time Delay
When power is applied to the input, the time delay begins. After the time delay is complete, the load energizes.- Highly precise digital timing
- Switch-settable time delays
- Ideal for ice machine applications
- Universal voltage operation
- Repeat accuracy .5% over voltage and temperature range
Input:
- Voltage: 18-240 VAC
- Frequency: 50-60 Hz
Output:
- Output Ratings:
- Maximum: 1 amp
- Minimum: 40 mA
- Inrush: 10 amps
Time Delay:1-1,023 seconds, switch settable in 1-second increments
Weight/Dimensions
- Weight: 0.1 lb.
- Height: 1.25″
- Width: 2″
- Length: 2″
A-1: 7061
Gemline: 1C213
Ice-O-Matic: TD3001A
Mars: 32394, 32396
Robertshaw: 3310-068
Supco: TMF-19, TMF-80
